Magnus Recessed Adjustable 4X

Illuminate your spaces with precision and efficiency using our advanced LED lighting Fixture. Designed to deliver uniform, homogeneous lighting with minimal spillover, this fixture maximizes lumens output while creating a clean, refined ambiance. Engineered with state-of-the-art Bartenbach optics, this fixture ensures top-tier energy efficiency, providing optimal brightness for any setting.Our LED light’s innovative design also reduces glare, making it ideal for a wide range of applications—from modern workspaces to cozy residential spaces. Upgrade to a lighting solution that combines sleek style with unparalleled performance.

product families

Dimensions of the Fixture

Choose Your Perfect Finish


Choose Your

beam angle

Filter Options

Filter By Color Temprature

Filter By Beam Angle

Filter By Wattage

Filter By Efficacy

Product Specifications

Color Temperature (CCT)Luminaire DimensionBeam AngleWattageLumensUGRIP RatingEfficacyProduct Code
2200KL 119 x H 6835°19 W1265 lm<9IP2066 lm/WMagnus Recessed 4X Adjustable 22K N
2200KL 119 x H 6853°19 W1310 lm<13IP2068 lm/WMagnus Recessed 4X Adjustable 22K M
2200KL 119 x H 6885°19 W1386 lm<26IP2073 lm/WMagnus Recessed 4X Adjustable 22K W
2700KL 119 x H 6835°19 W1317 lm<9IP2068 lm/WMagnus Recessed 4X Adjustable 27K N
2700KL 119 x H 6853°19 W1534 lm<19IP2080 lm/WMagnus Recessed 4X Adjustable 27K M
2700KL 119 x H 6885°19 W1629 lm<19IP2085 lm/WMagnus Recessed 4X Adjustable 27K W
3000KL 119 x H 6835°19 W1430 lm<9IP2075 lm/WMagnus Recessed 4X Adjustable 3K N 06
3000KL 119 x H 6853°19 W1611 lm<19IP2084 lm/WMagnus Recessed 4X Adjustable 3K M 05
3000KL 119 x H 6885°19 W1709 lm<26IP2089 lm/WMagnus Recessed 4X Adjustable 3K W 04
4000KL 119 x H 6835°19 W1589 lm <9IP2083 lm/WMagnus Recessed 4X Adjustable 4K N 03
4000KL 119 x H 6853°19 W1773 lm<16IP2093 lm/WMagnus Recessed 4X Adjustable 4K M 02
4000KL 119 x H 6885°19 W1762 lm<25IP2093 lm/WMagnus Recessed 4X Adjustable 4K W 01
5700KL 119 x H 6835°19 W1448 lm<9IP2076 lm/WMagnus Recessed 4X Adjustable 57K N
5700KL 119 x H 6854°19 W1636 lm<16IP2086 lm/WMagnus Recessed 4X Adjustable 57K M
5700KL 119 x H 6885°19 W1754 lm<25IP2091 lm/WMagnus Recessed 4X Adjustable 57K W
