Ray S Surface Downlight

Product Description

Illuminate your spaces with precision and efficiency using our advanced LED lighting Fixture. Designed to deliver uniform, homogeneous lighting with minimal spillover, this fixture maximizes lumens output while creating a clean, refined ambiance. Engineered with state-of-the-art Bartenbach optics, this fixture ensures top-tier energy efficiency, providing optimal brightness for any setting. Our LED light’s innovative design also reduces glare, making it ideal for a wide range of applications—from modern workspaces to cozy residential spaces. Upgrade to a lighting solution that combines sleek style with unparalleled performance.
Display Image
Display Image

Ray S Surface Downlight

gallery

Carefully crafted optics

in collaboration with

Bartenbach

Specially designed light optics, where the beam angle and the field angle are close and therefore light covers the whole target and has a sharp cut-off with no light spill outside.

Traditional Fixtures

Plus Light Tech’s Fixtures

State of the Art Optics

Our patented optic technology sets a new standard for lighting control and comfort boasting the industry's lowest UGR of less than 9 for all beam angles, minimising glare and maximising visual comfort. This precise light distribution allows for customisation. So, you can tune light output, achieve the perfect beam spread, and even mix colours with secondary optics. All this comes with the added benefit of exceptionally high lumen output, resulting in superior illumination and efficiency.

Design

Optics

Optic is developed with micro faceted structured just straight rectangular facets coated with Vacumm metalised Aluminum to have a 90% uniform concentrated light spread and 10% spill area.

Design

Build

Fixture Housing is made of Aluminum Pressure diecast ADC12 with special grade of powder coating PPG does not turn yellow over the lifespan of 10yrs. Fixture mounting is designed simply for ease of installation.

Design

Power Source

On-Off/ Dali2/DT8/AD/TD/BLE

Choose Your

beam angle

Product Specifications

Color Temperature (CCT)

Luminaire Dimension

Beam Angle

Wattage

Lumens

UGR

IP Rating

Product Code

Ray S Surface Downlight 4K 29º

Color Temperature (CCT)

4000K

Luminaire Dimension

-

Beam Angle

29º

Wattage

19 W

Lumens

2111 lm

UGR

<19

IP Rating

IP20
Ray S Surface Downlight 4K 43º

Color Temperature (CCT)

4000K

Luminaire Dimension

-

Beam Angle

43º

Wattage

19 W

Lumens

2141 lm

UGR

<20

IP Rating

IP20
Ray S Surface Downlight 4K 21º

Color Temperature (CCT)

4000K

Luminaire Dimension

-

Beam Angle

21º

Wattage

19 W

Lumens

2099 lm

UGR

<18

IP Rating

IP20
Ray S Surface Downlight 4K 80º

Color Temperature (CCT)

4000K

Luminaire Dimension

-

Beam Angle

80º

Wattage

19 W

Lumens

1809 lm

UGR

<25

IP Rating

IP20
Ray S Surface Downlight 3.5K 21º

Color Temperature (CCT)

3500K

Luminaire Dimension

-

Beam Angle

21º

Wattage

19 W

Lumens

1647 lm

UGR

<18

IP Rating

IP20
Ray S Surface Downlight 3K 29º

Color Temperature (CCT)

3000K

Luminaire Dimension

-

Beam Angle

29º

Wattage

19 W

Lumens

1896 lm

UGR

<19

IP Rating

IP20
Ray S Surface Downlight 3K 21º

Color Temperature (CCT)

3000K

Luminaire Dimension

-

Beam Angle

21º

Wattage

19 W

Lumens

1928 lm

UGR

<18

IP Rating

IP20
Ray S Surface Downlight 3.5K 43º

Color Temperature (CCT)

3500K

Luminaire Dimension

-

Beam Angle

43º

Wattage

19 W

Lumens

1666 lm

UGR

<19

IP Rating

IP20
Ray S Surface Downlight 3.5K 79º

Color Temperature (CCT)

3500K

Luminaire Dimension

-

Beam Angle

79º

Wattage

19 W

Lumens

1468 lm

UGR

<24

IP Rating

IP20
Ray S Surface Downlight 3.5K 29º

Color Temperature (CCT)

3500K

Luminaire Dimension

-

Beam Angle

29º

Wattage

19 W

Lumens

1701 lm

UGR

<17

IP Rating

IP20

Filter Options

Filter By Color Temprature

Filter By Beam Angle

Filter By Wattage

Filter By Efficacy

Product Specifications

Color Temperature (CCT) Luminaire Dimension Beam Angle Wattage Lumens UGR IP Rating Efficacy Product Code
3000K - 21º 19W 1928 lm <18 IP20 103 lm/W Ray S Surface Downlight 3K 21º
3000K - 29º 19W 1896 lm <19 IP20 101 lm/W Ray S Surface Downlight 3K 29º
3000K - 43º 17W 1646 lm <19 IP20 99 lm/W Ray S Surface Downlight 3K 43º
3000K - 81º 18W 1658 lm <24 IP20 90 lm/W Ray S Surface Downlight 3K 81º
3500K - 21º 19W 1647 lm <18 IP20 88 lm/W Ray S Surface Downlight 3.5K 21º
3500K - 29º 19W 1701 lm <17 IP20 92 lm/W Ray S Surface Downlight 3.5K 29º
3500K - 43º 19W 1666 lm <19 IP20 89 lm/W Ray S Surface Downlight 3.5K 43º
3500K - 79º 19W 1468 lm <24 IP20 79 lm/W Ray S Surface Downlight 3.5K 79º
4000K - 21º 19W 2099 lm <18 IP20 111 lm/W Ray S Surface Downlight 4K 21º
4000K - 29º 19W 2111 lm <19 IP20 111 lm/W Ray S Surface Downlight 4K 29º
4000K - 43º 19W 2141 lm <20 IP20 113 lm/W Ray S Surface Downlight 4K 43º
4000K - 80º 19W 1809 lm <25 IP20 96 lm/W Ray S Surface Downlight 4K 80º

Dimensions

PL06822

/ Downloads

Technical Data

Photometric data: IES
