Product Specifications
| Color Temperature (CCT) | Luminaire Dimension | Beam Angle | Wattage | Lumens | UGR | IP Rating | Efficacy | Download TDS |
|---|---|---|---|---|---|---|---|---|
| 5700K | L 130 x H 135 | 35º | 24 W | 2146 lm | <9 | IP20 | 91 lm/W | NIX TRACK 57K N |
| 5700K | L 130 x H 135 | 53º | 24 W | 2270 lm | <18 | IP20 | 95 lm/W | NIX TRACK 57K M |
| 5700K | L 130 x H 135 | 87º | 24 W | 2495 lm | <24 | IP20 | 105 lm/W | NIX TRACK 57K W |
| 4000K | L 130 x H 135 | 35º | 23 W | 2280 lm | <9 | IP20 | 98 lm/W | NIX TRACK 4K N |
| 4000K | L 130 x H 135 | 53º | 23 W | 2428 lm | <16 | IP20 | 104 lm/W | NIX TRACK 4K M |
| 4000K | L 130 x H 135 | 87º | 24 W | 2543 lm | <26 | IP20 | 108 lm/W | NIX TRACK 4K W |
| 3000K | L 130 x H 135 | 35º | 24 W | 2116 lm | <9 | IP20 | 88 lm/W | NIX TRACK 3K N |
| 3000K | L 130 x H 135 | 53º | 24 W | 2173 lm | <18 | IP20 | 90 lm/W | NIX TRACK 3K M |
| 3000K | L 130 x H 135 | 87º | 24 W | 2255 lm | <24 | IP20 | 95 lm/W | NIX TRACK 3K W |
| 2700K | L 130 x H 135 | 35º | 24 W | 1889 lm | <9 | IP20 | 80 lm/W | NIX TRACK 27K N |
| 2700K | L 130 x H 135 | 53º | 24 W | 2030 lm | <18 | IP20 | 85 lm/W | NIX TRACK 27K M |
| 2700K | L 130 x H 135 | 87º | 24 W | 2102 lm | <26 | IP20 | 89 lm/W | NIX TRACK 27K W |
| 2200K | L 130 x H 135 | 35º | 24 W | 1553 lm | <9 | IP20 | 65 lm/W | NIX TRACK 22K N |
| 2200K | L 130 x H 135 | 53º | 24 W | 1644 lm | <18 | IP20 | 69 lm/W | NIX TRACK 22K M |
| 2200K | L 130 x H 135 | 87º | 24 W | 1681 lm | <24 | IP20 | 71 lm/W | NIX TRACK 22K W |
