ELITE WW S

ELITE, SURFACE

These ceiling-mounted wallwasher fixtures are built out of modular and linkable sections to illuminate the intended area with uniform distribution, placing the driver remotely

Lighting Effects

MAX LAMP LUMEN
1764 lm
SYSTEM WATTAGE
20W(max)
DC CURRENT
500mA (max)
EFFICIENCY
72% (approx)
INPUT
220-240V ~ 50/60Hz
CCT [K]
2200, 2700, 3000, 3100, 3500, 4000, 5700
DRIVER
Remote Electronic
TUNABLE & DIMMABLE
On Request
IP RATING
IP 20
BEAM ANGLE
90° longitudinal direction wall
5°–90° towards wall
UGR VALUE
<19
CRI
97 (Max)
WARRANTY
2 Years

COLOUR/FINISH
- White
- Black
- Silver

The new reflector technology produces homogenous colour mixing within one reflector cell and renders multiple light distributions and reflector arrangements.
