Nova M

Product Description

Illuminate your spaces with precision and efficiency using our advanced LED lighting Fixture. Designed to deliver uniform, homogeneous lighting with minimal spillover, this fixture maximizes lumens output while creating a clean, refined ambiance. Engineered with state-of-the-art Bartenbach optics, this fixture ensures top-tier energy efficiency, providing optimal brightness for any setting. Our LED light’s innovative design also reduces glare, making it ideal for a wide range of applications—from modern workspaces to cozy residential spaces. Upgrade to a lighting solution that combines sleek style with unparalleled performance.
Display Image
Display Image

Nova M

gallery

Carefully crafted optics

in collaboration with

Bartenbach

Specially designed light optics, where the beam angle and the field angle are close and therefore light covers the whole target and has a sharp cut-off with no light spill outside.

Traditional Fixtures

Plus Light Tech’s Fixtures

State of the Art Optics

Our patented optic technology sets a new standard for lighting control and comfort boasting the industry's lowest UGR of less than 9 for all beam angles, minimising glare and maximising visual comfort. This precise light distribution allows for customisation. So, you can tune light output, achieve the perfect beam spread, and even mix colours with secondary optics. All this comes with the added benefit of exceptionally high lumen output, resulting in superior illumination and efficiency.

Design

Optics

Optic is developed with micro faceted structured just straight rectangular facets coated with Vacumm metalised Aluminum to have a 90% uniform concentrated light spread and 10% spill area.

Design

Build

Fixture Housing is made of Aluminum Pressure diecast ADC12 with special grade of powder coating PPG does not turn yellow over the lifespan of 10yrs. Fixture mounting is designed simply for ease of installation.

Design

Power Source

Choose Your

beam angle

Product Specifications

Color Temperature (CCT)

Luminaire Dimension

Beam Angle

Wattage

Lumens

UGR

IP Rating

Product Code

Nova M Recessed Spotlight 4K 75º

Color Temperature (CCT)

4000K

Luminaire Dimension

L 149 x H 129

Beam Angle

75º

Wattage

41 W

Lumens

3169 lm

UGR

<26

IP Rating

IP20
Nova M Recessed Spotlight 4K 43º

Color Temperature (CCT)

4000K

Luminaire Dimension

L 149 x H 129

Beam Angle

43º

Wattage

41 W

Lumens

3934 lm

UGR

<22

IP Rating

IP20
Nova M Recessed Spotlight 4K 29º

Color Temperature (CCT)

4000K

Luminaire Dimension

L 149 x H 129

Beam Angle

29º

Wattage

41 W

Lumens

4101 lm

UGR

<19

IP Rating

IP20
Nova M Recessed Spotlight 4K 21º

Color Temperature (CCT)

4000K

Luminaire Dimension

L 149 x H 129

Beam Angle

21º

Wattage

41 W

Lumens

3961 lm

UGR

<19

IP Rating

IP20
Nova M Recessed Spotlight 3.5K 76º

Color Temperature (CCT)

3500K

Luminaire Dimension

L 149 x H 129

Beam Angle

76º

Wattage

41 W

Lumens

3337 lm

UGR

<24

IP Rating

IP20
Nova M Recessed Spotlight 3.5K 44º

Color Temperature (CCT)

3500K

Luminaire Dimension

L 149 x H 129

Beam Angle

44º

Wattage

41 W

Lumens

4010 lm

UGR

<19

IP Rating

IP20
Nova M Recessed Spotlight 3.5K 29º

Color Temperature (CCT)

3500K

Luminaire Dimension

L 149 x H 129

Beam Angle

29º

Wattage

41 W

Lumens

3772 lm

UGR

<19

IP Rating

IP20
Nova M Recessed Spotlight 3.5K 21º

Color Temperature (CCT)

3500K

Luminaire Dimension

L 149 x H 129

Beam Angle

21º

Wattage

41 W

Lumens

3927 lm

UGR

<18

IP Rating

IP20
Nova M Recessed Spotlight 3K 75º

Color Temperature (CCT)

3000K

Luminaire Dimension

L 149 x H 129

Beam Angle

75º

Wattage

40 W

Lumens

3123 lm

UGR

<25

IP Rating

IP20
Nova M Recessed Spotlight 3K 43º

Color Temperature (CCT)

3000K

Luminaire Dimension

L 149 x H 129

Beam Angle

43º

Wattage

40 W

Lumens

3572 lm

UGR

<21

IP Rating

IP20

Filter Options

Filter By Color Temprature

Filter By Beam Angle

Filter By Wattage

Filter By Efficacy

Product Specifications

Color Temperature (CCT) Luminaire Dimension Beam Angle Wattage Lumens UGR IP Rating Efficacy Product Code
3000K L 149 x H 129 20º 40 W 3585 lm < 18 IP20 89 lm/W Nova M Recessed Spotlight 3K 20º
3000K L 149 x H 129 30º 40 W 3604 lm < 20 IP20 89 lm/W Nova M Recessed Spotlight 3K 30º
3000K L 149 x H 129 43º 40 W 3572 lm < 21 IP20 89 lm/W Nova M Recessed Spotlight 3K 43º
3000K L 149 x H 129 75º 40 W 3123 lm < 25 IP20 78 lm/W Nova M Recessed Spotlight 3K 75º
3500K L 149 x H 129 21º 41 W 3927 lm < 18 IP20 95 lm/W Nova M Recessed Spotlight 3.5K 21º
3500K L 149 x H 129 29º 41 W 3772 lm < 19 IP20 92 lm/W Nova M Recessed Spotlight 3.5K 29º
3500K L 149 x H 129 44º 41 W 4010 lm < 19 IP20 97 lm/W Nova M Recessed Spotlight 3.5K 44º
3500K L 149 x H 129 76º 41 W 3337 lm < 24 IP20 81 lm/W Nova M Recessed Spotlight 3.5K 76º
4000K L 149 x H 129 21º 41 W 3961 lm < 19 IP20 97 lm/W Nova M Recessed Spotlight 4K 21º
4000K L 149 x H 129 29º 41 W 4101 lm < 19 IP20 100 lm/W Nova M Recessed Spotlight 4K 29º
4000K L 149 x H 129 43º 41 W 3934 lm < 22 IP20 96 lm/W Nova M Recessed Spotlight 4K 43º
4000K L 149 x H 129 75º 41 W 3169 lm < 26 IP20 77 lm/W Nova M Recessed Spotlight 4K 75º

Dimensions

PL06822

/ Downloads

Technical Data

Photometric data: IES
