S Spot Pendant Segmented

Product Description

Illuminate your spaces with precision and efficiency using our advanced LED lighting Fixture. Designed to deliver uniform, homogeneous lighting with minimal spillover, this fixture maximizes lumens output while creating a clean, refined ambiance. Engineered with state-of-the-art Bartenbach optics, this fixture ensures top-tier energy efficiency, providing optimal brightness for any setting. Our LED light’s innovative design also reduces glare, making it ideal for a wide range of applications—from modern workspaces to cozy residential spaces. Upgrade to a lighting solution that combines sleek style with unparalleled performance.
Display Image
Display Image

S Spot Pendant Segmented

gallery

Carefully crafted optics

in collaboration with

Bartenbach

Specially designed light optics, where the beam angle and the field angle are close and therefore light covers the whole target and has a sharp cut-off with no light spill outside.

View PLUS TECHNOLOGY

Traditional Fixtures

Plus Light Tech’s Fixtures

State of the Art Optics

Our patented optic technology sets a new standard for lighting control and comfort boasting the industry's lowest UGR of less than 9 for all beam angles, minimising glare and maximising visual comfort. This precise light distribution allows for customisation. So, you can tune light output, achieve the perfect beam spread, and even mix colours with secondary optics. All this comes with the added benefit of exceptionally high lumen output, resulting in superior illumination and efficiency.

View PLUS TECHNOLOGY

Design

Optics

Optic is developed with micro faceted structured just straight rectangular facets coated with Vacumm metalised Aluminum to have a 90% uniform concentrated light spread and 10% spill area.

Design

Build

Fixture Housing is made of Aluminum Pressure diecast ADC12 with special grade of powder coating PPG does not turn yellow over the lifespan of 10yrs. Fixture mounting is designed simply for ease of installation.

Design

Power Source

On-Off/ DT2/DT8/BLE/AD/ TD

Choose Your

beam angle

Product Specifications

Color Temperature (CCT)

Luminaire Dimension

Beam Angle

Wattage

Lumens

UGR

IP Rating

Product Code

No data was found

Filter Options

Filter By Color Temprature

Filter By Beam Angle

Filter By Wattage

Filter By Efficacy

Product Specifications

Color Temperature (CCT) Luminaire Dimension Beam Angle Wattage Lumens UGR IP Rating Efficacy Product Code
3000K - 17Âş 35W 3171 lm < 17 IP20 90 lm/W S Spot Pendant Downlight 3K 17Âş
3000K - 27Âş 35W 2966 lm < 15 IP20 84 lm/W S Spot Pendant Downlight 3K 27Âş
3000K - 44Âş 35W 2724 lm < 16 IP20 77 lm/W S Spot Pendant Downlight 3K 44Âş
3000K - 61Âş 35W 2952 lm < 20 IP20 84 lm/W S Spot Pendant Downlight 3K 61Âş
4000K - 18º 36W 3597 lm < 17 IP20 100 lm/W S Spot Pendant Downlight 4K 17°
4000K - 28º 36W lm < 16 IP20 91 lm/W S Spot Pendant Downlight 4K 27°
4000K - 43º 36W 3137 lm < 17 IP20 87 lm/W S Spot Pendant Downlight 4K 44°
4000K - 61Âş 36W 3323 lm < 20 IP20 92 lm/W S Spot Pendant Downlight 4K 61Âş

Dimensions

PL06822

/ Downloads

Technical Data

Photometric data: IES
