Tumblerr Spike

Product Description

Illuminate your spaces with precision and efficiency using our advanced LED lighting Fixture. Designed to deliver uniform, homogeneous lighting with minimal spillover, this fixture maximizes lumens output while creating a clean, refined ambiance. Engineered with state-of-the-art Bartenbach optics, this fixture ensures top-tier energy efficiency, providing optimal brightness for any setting. Our LED light’s innovative design also reduces glare, making it ideal for a wide range of applications—from modern workspaces to cozy residential spaces. Upgrade to a lighting solution that combines sleek style with unparalleled performance.
Display Image
Display Image

Tumblerr Spike

gallery

Carefully crafted optics

in collaboration with

Bartenbach

Specially designed light optics, where the beam angle and the field angle are close and therefore light covers the whole target and has a sharp cut-off with no light spill outside.

Traditional Fixtures

Plus Light Tech’s Fixtures

State of the Art Optics

Our patented optic technology sets a new standard for lighting control and comfort boasting the industry's lowest UGR of less than 9 for all beam angles, minimising glare and maximising visual comfort. This precise light distribution allows for customisation. So, you can tune light output, achieve the perfect beam spread, and even mix colours with secondary optics. All this comes with the added benefit of exceptionally high lumen output, resulting in superior illumination and efficiency.

Design

Optics

The re-engineered reflector mechanics reduces field angles and improves the uniformity of the beams. Tumblerr family reflectors are compact solutions for outdoor Wallmount,Garden Spike light and Bollards. Beam angle option here is 15/28/38/55

Design

Build

Fixture housing is constructed with Pure Aluminum CNC Machined Grade with copper content less than 1% to have uniform outdoor grade different anodized finish or special powder coating RAL7016/RAL7002/RAL9005 having higher salt spray life tested 1000hrs

Design

Power Source

On-Off/Dali2.0 Dim

Choose Your

beam angle

Product Specifications

Color Temperature (CCT)

Luminaire Dimension

Beam Angle

Wattage

Lumens

UGR

IP Rating

Product Code

Tumblerr Spike Mounted

Color Temperature (CCT)

2700K - 5700K

Luminaire Dimension

L 80 x H 303

Beam Angle

28° / 35° / 48° / 62°

Wattage

10 W

Lumens

900 - 1050 lm

UGR

<10

IP Rating

IP67

Filter Options

Filter By Color Temprature

Filter By Beam Angle

Filter By Wattage

Filter By Efficacy

Product Specifications

Color Temperature (CCT) Luminaire Dimension Beam Angle Wattage Lumens UGR IP Rating Efficacy Product Code
2700K - 5700K L 80 x H 303 28° / 35° / 48° / 62° 10 W 900 - 1050 lm <10 IP67 92 lm/W Tumblerr Spike Mounted 01

Dimensions

PL06822

/ Downloads

Technical Data

Photometric data: IES
