Product Specifications
| Color Temperature (CCT) | Luminaire Dimension | Beam Angle | Wattage | Lumens | UGR | IP Rating | Efficacy | Download TDS |
|---|---|---|---|---|---|---|---|---|
| 5700K | L 198 x H 68 | 49° | 22 W | 1590 lm | <19 | IP20 | 72 lm/W | Zona Facia Linear 6x Trimless 57K W |
| 5700K | L 198 x H 68 | 33° | 22 W | 1361 lm | <9 | IP20 | 62 lm/W | Zona Facia Linear 6x Trimless 57K N |
| 4000K | L 198 x H 68 | 48° | 22 W | 1579 lm | <21 | IP20 | 70 lm/W | Zona Facia Linear 6x Trimless 4K W 01 |
| 4000K | L 198 x H 68 | 33° | 22 W | 1463 lm | <9 | IP20 | 65 lm/W | Zona Facia Linear 6x Trimless 4K N 02 |
| 3000K | L 198 x H 68 | 49° | 23 W | 1492 lm | <20 | IP20 | 66 lm/W | Zona Facia Linear 6x Trimless 3K W 03 |
| 3000K | L 198 x H 68 | 33° | 23 W | 1387 lm | <9 | IP20 | 61 lm/W | Zona Facia Linear 6x Trimless 3K N 04 |
| 2700K | L 198 x H 68 | 49° | 22 W | 1379 lm | <920 | IP20 | 62 lm/W | Zona Facia Linear 6x Trimless 27K W |
| 2700K | L 198 x H 68 | 33° | 22 W | 1111 lm | <9 | IP20 | 51 lm/W | Zona Facia Linear 6x Trimless 27K N |
Location: Bartenbach GmbH, Austria
