Scopic
SCOPIC SHD 8X
Scopic is built for powerful outdoor performance with minimal maintenance. Engineered with IP65 protection and IK07 to IK10 impact resistance, it can withstand tough weather and harsh environments. The fixture features advanced IR-coated optics for excellent light output and superior transmission, all while maintaining a condensation-free design. Its UV-resistant, corrosion-proof finish ensures it stays looking new over time. With wide beam coverage, Scopic lights up more area with fewer fixtures—making it both efficient and cost-effective.
<9
APERTURE SIZE
00 mm
LUMENS
1609-2212 lm
EFFICACY
78 lm/W
90+
BEAM ANGLES
41º, 135º
Superior Light Transmission
Crafted with Hecker glass, delivering up to 98% light transmission for brighter, more effective illumination with minimal loss.
Advanced IR-Coated Optics
Features special IR-coated glass that significantly reduces reflective and transmission losses — maximizing lighting performance and energy efficiency.
Condensation-Free Design
Engineered with an integrated air-vent system to prevent internal condensation, ensuring consistent performance in all weather conditions.
Corrosion-Resistant Finish
Protected with a rust-proof, corrosion-resistant powder coating, built to withstand extreme outdoor environments for years.
Rugged Outdoor Protection
Designed with IP65 and IK07 to IK10 ratings, ensuring durability against water, dust, and impact — ideal for harsh outdoor conditions.
UV-Resistant Build
Constructed with anti-UV materials (Level 8 resistance) to prevent discoloration and degradation under prolonged sun exposure.
Wide Coverage. Fewer Fixtures.
Each fixture is optimized to cover larger areas, reducing the total number of fixtures needed — lowering costs and simplifying installation.
Carefully crafted optics
in collaboration with
Bartenbach
Specially designed light optics, where the beam angle and the field angle are close and therefore light covers the whole target and has a sharp cut-off with no light spill outside.Â
Traditional Fixtures

Plus Light Tech’s Fixtures





gallery




All dimensions are in mm.
